1. Rated Parameters

Input voltage range： 198~242VAC, 50/60Hz

Rated output power： 40W / 80W@1350RPM

Efficiency：>70%

Controller MTBF : 50,000 H

2. Environmental conditions

Temperature：-10~50°C

Monthly averaged humidity：<90%RH，Non condensation

S1 Continuously working

3. Storage condition

Temperature：-30~70°C, RH：10~90% , Non condensation

4. Motor Protections

Lock rotor protection

Loss of synchronism protection

Overcurrent & short-circuit protection

Phase loss protection

AC input overvoltage protection: 270±2%VAC

AC input low voltage protection: 170±2%VAC

Power module over temperature protection

PCBA over temperature protection
