Model Number
- BLS(D)K series
Rated Parameters
- Input voltage range: 198~242 V AC, 50/60 Hz
- Rated output power: 40 W / 80 W @ 1,350 RPM
- Efficiency: >70%
- Controller MTBF: 50,000 h
Ambient Conditions
- Ambient temperature: -10 °C to +50 °C
- Average relative humidity: <90% RH, non-condensing
- Duty type: S1
Storage Conditions
- Storage temperature: -30 °C to +70 °C
- Storage humidity: 10% to 90% RH, non-condensing
Protection Functions
- Locked-rotor protection
- Loss of synchronism (out-of-step) protection
- Over-current and short-circuit protection
- Phase-loss protection
- AC input over-voltage protection: 270 V AC ±2%
- AC input under-voltage protection: 170 V AC ±2%
- Power module over-temperature protection
- PCBA over-temperature protection
